Securing YCQL End-to-End: TLS, EAR, and Client-Side Encryption

When most people talk about encryption in YugabyteDB, they focus on the YSQL API which includes PostgreSQL’s pgcrypto functions for encrypting and decrypting columns directly in SQL.

But YCQL (the Cassandra-compatible API) can be just as secure … you just apply encryption at the infrastructure and client layers.

In this YugabyteDB Tip, we’ll walk through how to secure YCQL end-to-end:

Using yugabyted --secure to enable encryption in transit and at rest.
Using client-side field-level encryption (FLE) in Python to encrypt individual columns before they ever leave your app.

You’ll end up with a YCQL table where data is:

● Encrypted on the wire ✅
● Encrypted on disk ✅
● Encrypted in the client before it’s sent ✅

Step 1: Start a Secure YugabyteDB Cluster

The easiest way to enable encryption in both directions is to start YugabyteDB with the --secure flag.


					./bin/yugabyted start --secure

This automatically:

● Generates local TLS certificates.
● Enables client-to-server and server-to-server TLS.
● Enables encryption at rest for data files and WALs.

You’ll see log output confirming:


					Starting yugabyted...
✅ YugabyteDB Started
✅ Encryption in Transit and Password Authentication enabled
✅ UI ready
✅ Data placement constraint successfully verified
...

DB_PASSWORD is saved in the Credentials File.
Credentials File is stored at /root/var/data/yugabyted_credentials.txt

Once it starts, YCQL is available on port 9042 with secure connections.

💡 Note: If you’re deploying with YugabyteDB Anywhere (YBA), you can achieve the same by enabling TLS during universe creation. YBA automatically handles certificate generation and rotation for secure node and client communication.

Step 2: Create a Secure Keyspace and Table

Connect to YCQL using the secure shell:


					[root@localhost ~]# grep "YCQL Credentials:"  /root/var/data/yugabyted_credentials.txt -A 2
YCQL Credentials:
Username: cassandra
Password: LnQs3rvICdn2

[root@localhost ~]# SSL_CERTFILE=/root/var/generated_certs/root-ca/ca.crt ycqlsh -u cassandra -p LnQs3rvICdn2 --ssl
Connected to local cluster at 127.0.0.1:9042.
[ycqlsh 5.0.1 | Cassandra 3.9-SNAPSHOT | CQL spec 3.4.2 | Native protocol v4]
Use HELP for help.
cassandra@ycqlsh>

Then create a keyspace and table:


					CREATE KEYSPACE secure_ks;

CREATE TABLE secure_ks.customers (
  id        int PRIMARY KEY,
  ssn       blob,         -- client-encrypted
  cc_number blob          -- client-encrypted
);

Step 3: Install Python Dependencies

(Next we’ll demo one of many ways to perform Client-Side Encryption)

Set up a quick virtual environment:


					python3 -m venv venv
source venv/bin/activate
pip install cassandra-driver cryptography

** Requires DataStax Python Driver 3.28.0 or higher **

Step 4: Run the Demo Script

Save the following as ycql_secure.py:


					# ycql_secure.py
import os, ssl
from cassandra.cluster import Cluster
from cassandra.auth import PlainTextAuthProvider
from cassandra.policies import ColDesc
from cassandra.column_encryption.policies import (
    AES256ColumnEncryptionPolicy,
    AES256_KEY_SIZE_BYTES,
)

# --- keys (demo only) ---
ssn_key = os.urandom(AES256_KEY_SIZE_BYTES)
cc_key  = os.urandom(AES256_KEY_SIZE_BYTES)

# --- column encryption policy ---
policy = AES256ColumnEncryptionPolicy()
policy.add_column(ColDesc("secure_ks", "customers", "ssn"), ssn_key, "text")
policy.add_column(ColDesc("secure_ks", "customers", "cc_number"), cc_key, "text")

# --- TLS + auth (matches your ycqlsh command) ---
ssl_ctx = ssl.create_default_context(cafile="/root/var/generated_certs/root-ca/ca.crt")
auth = PlainTextAuthProvider(username="cassandra", password="LnQs3rvICdn2")

cluster = Cluster(
    ["127.0.0.1"],            # or your tserver IPs
    port=9042,
    ssl_context=ssl_ctx,
    auth_provider=auth,
    column_encryption_policy=policy,
)
session = cluster.connect()

# >>> Use PREPARED statements so the driver can encrypt bound params <<<
ins = session.prepare("""
    INSERT INTO secure_ks.customers (id, ssn, cc_number) VALUES (?, ?, ?)
""")
session.execute(ins, (1, "111-22-3333", "4111111111111111"))

sel = session.prepare("SELECT ssn, cc_number FROM secure_ks.customers WHERE id = ?")
row = session.execute(sel, (1,)).one()

print("✅ Decrypted client-side:")
print("SSN:", row.ssn)
print("Card:", row.cc_number)

Run it:


					python ycql_secure.py

Expected output:


					✅ Decrypted client-side:
SSN: 111-22-3333
Card: 4111111111111111

Step 5: Verify What’s Stored in YCQL

Check the raw data on the server. You’ll see ciphertext, not plaintext:


					[root@localhost ~]# SSL_CERTFILE=/root/var/generated_certs/root-ca/ca.crt ycqlsh -u cassandra -p LnQs3rvICdn2 --ssl -e "SELECT id, ssn, cc_number FROM secure_ks.customers;"

 id | ssn                                                                | cc_number
----+--------------------------------------------------------------------+----------------------------------------------------------------------------------------------------
  1 | 0xbdd83bf917533dd105522ea4659377b5f7e4cc3f08ddf8ed3a1e169a6f096f58 | 0xbdd83bf917533dd105522ea4659377b5c591dee17aee1a9541f3f935c2170c01ef73064aaf3aef651142878bc6e0acde

(1 rows)

Summary

With a single --secure flag and a few lines of Python, you’ve achieved:

● Encryption in transit ✅
● Encryption at rest ✅
● Field-level encryption in the client ✅

No plaintext ever leaves your application, making this approach ideal for finance, healthcare, or defense workloads that require strict compliance.

Have Fun!
