Query SQL Server Data from YugabyteDB Using FDW (POC-Friendly)

Jim Knicely
Why this tip exists

Sometimes you just want to prove it’s possible:

  • ● “Can YugabyteDB read data from SQL Server?”

  • ● “Can I explore SQL Server tables from YSQL without exporting data?”

  • ● “Can I do a quick POC before committing to CDC / ETL / migration tooling?”

This tip shows a fast, local POC pattern using:

  • ● SQL Server (Docker)

  • ● PostgreSQL + tds_fdw as a lightweight bridge

  • ● YugabyteDB (YSQL) using built-in postgres_fdw

⚠️ Important framing

  • ● This is not a production ingestion pattern

  • ● FDWs are best for POCs, exploration, and validation

  • ● For scale & performance, move to CDC/ETL later

What we’re building (high level)

					YugabyteDB (YSQL)
   |
   | postgres_fdw
   v
PostgreSQL (bridge)
   |
   | tds_fdw (TDS protocol)
   v
SQL Server (Docker)
Prerequisites

  • ● AlmaLinux 9 VM

  • ● Docker installed and running

  • ● YugabyteDB running via yugabyted

Confirm YugabyteDB is up and running:


					yugabyted status >/dev/null && echo "✅ YugabyteDB is running"

Example:


					[root@localhost ~]# yugabyted start > start.log

[root@localhost ~]# yugabyted status >/dev/null && echo "✅ YugabyteDB is running"
✅ YugabyteDB is running
Step 1️⃣: Create a Docker network (quietly)

					docker network create fdw-net >/dev/null
echo "✅ Docker network fdw-net created"
Step 2️⃣: Start SQL Server (minimal output)

					docker run -d --name mssql \
  --network fdw-net \
  -e ACCEPT_EULA=Y \
  -e MSSQL_SA_PASSWORD=Str0ngP@ssw0rd! \
  -p 1433:1433 \
  mcr.microsoft.com/mssql/server:2022-latest >/dev/null

echo "✅ SQL Server container started"

Give it ~30 seconds to initialize.

Step 3️⃣: Create a dog-themed demo table in SQL Server 🐕
3a. Create database

					docker exec mssql /opt/mssql-tools18/bin/sqlcmd \
  -S localhost -U sa -P 'Str0ngP@ssw0rd!' -C -b \
  -Q "IF DB_ID('dog_demo') IS NULL CREATE DATABASE dog_demo;"
echo "✅ SQL Server: database dog_demo created"
3b. Create table

					docker exec mssql /opt/mssql-tools18/bin/sqlcmd \
  -S localhost -U sa -P 'Str0ngP@ssw0rd!' -C -b -d dog_demo \
  -Q "IF OBJECT_ID('dbo.dog_breeds','U') IS NOT NULL DROP TABLE dbo.dog_breeds;
      CREATE TABLE dbo.dog_breeds (
        breed NVARCHAR(50) NOT NULL,
        top_name NVARCHAR(50) NOT NULL,
        avg_weight_lbs INT NOT NULL
      );"
echo "✅ SQL Server: table dbo.dog_breeds created"
3c. Insert 5 rows

					docker exec mssql /opt/mssql-tools18/bin/sqlcmd \
  -S localhost -U sa -P 'Str0ngP@ssw0rd!' -C -b -d dog_demo \
  -Q "INSERT INTO dbo.dog_breeds VALUES
      ('Labrador Retriever','Buddy',65),
      ('German Shepherd','Max',75),
      ('Golden Retriever','Charlie',70),
      ('French Bulldog','Luna',28),
      ('Beagle','Cooper',25);"
echo "✅ SQL Server: inserted 5 dog rows"
3d. Verify:

					docker exec mssql /opt/mssql-tools18/bin/sqlcmd \
  -S localhost -U sa -P 'Str0ngP@ssw0rd!' -C -b -d dog_demo \
  -h -1 -W -Q "SET NOCOUNT ON; SELECT 'rows_loaded=' + CAST(COUNT(*) AS varchar(10)) FROM dbo.dog_breeds;"

Example:


					[root@localhost ~]# docker exec mssql /opt/mssql-tools18/bin/sqlcmd \
-S localhost -U sa -P 'Str0ngP@ssw0rd!' -C -b -d dog_demo \
-h -1 -W -Q "SET NOCOUNT ON; SELECT 'rows_loaded=' + CAST(COUNT(*) AS varchar(10)) FROM dbo.dog_breeds;"
rows_loaded=5
Step 4️⃣: Start the PostgreSQL bridge container

					docker run -d --name pgbridge \
  --network fdw-net \
  -e POSTGRES_PASSWORD=postgres \
  -p 55432:5432 \
  postgres:16 >/dev/null

echo "✅ PostgreSQL bridge container started"
Step 5️⃣: Install tds_fdw inside the bridge (quiet build)

					docker exec pgbridge bash -lc "
apt-get update -qq &&
apt-get install -y -qq git build-essential postgresql-server-dev-16 freetds-dev &&
git clone -q https://github.com/tds-fdw/tds_fdw.git /tmp/tds_fdw &&
cd /tmp/tds_fdw &&
make USE_PGXS=1 >/dev/null &&
make USE_PGXS=1 install >/dev/null
"

docker exec pgbridge psql -U postgres -c "CREATE EXTENSION tds_fdw;" >/dev/null
echo "✅ tds_fdw installed in bridge Postgres"
Step 6️⃣: Expose SQL Server table in Postgres via tds_fdw

					docker exec pgbridge psql -U postgres -v ON_ERROR_STOP=1 -c "
CREATE SERVER mssql_srv
  FOREIGN DATA WRAPPER tds_fdw
  OPTIONS (servername 'mssql', port '1433', database 'dog_demo');

CREATE USER MAPPING FOR postgres
  SERVER mssql_srv
  OPTIONS (username 'sa', password 'Str0ngP@ssw0rd!');

CREATE FOREIGN TABLE public.mssql_dog_breeds (
  breed text,
  top_name text,
  avg_weight_lbs int
)
SERVER mssql_srv
OPTIONS (schema_name 'dbo', table_name 'dog_breeds');
" >/dev/null

echo "✅ SQL Server exposed via tds_fdw"

Quick check (optional):


					docker exec pgbridge psql -U postgres -c \
"SELECT * FROM public.mssql_dog_breeds ORDER BY avg_weight_lbs DESC;"

Example:


					[root@localhost ~]# docker exec pgbridge psql -U postgres -c \
"SELECT * FROM public.mssql_dog_breeds ORDER BY avg_weight_lbs DESC;"
NOTICE:  tds_fdw: Query executed correctly
NOTICE:  tds_fdw: Getting results
NOTICE:  tds_fdw: Query executed correctly
NOTICE:  tds_fdw: Getting results
       breed        | top_name | avg_weight_lbs
--------------------+----------+----------------
 German Shepherd    | Max      |             75
 Golden Retriever   | Charlie  |             70
 Labrador Retriever | Buddy    |             65
 French Bulldog     | Luna     |             28
 Beagle             | Cooper   |             25
(5 rows)
Step 7️⃣: Query SQL Server data from YugabyteDB 🎉

Connect to YSQL:


					ysqlsh -h 127.0.0.1 -p 5433 -U yugabyte -d yugabyte

Create FDW objects:


					CREATE EXTENSION IF NOT EXISTS postgres_fdw;

CREATE SERVER pgbridge_srv
  FOREIGN DATA WRAPPER postgres_fdw
  OPTIONS (host '127.0.0.1', port '55432', dbname 'postgres');

CREATE USER MAPPING FOR yugabyte
  SERVER pgbridge_srv
  OPTIONS (user 'postgres', password 'postgres');

CREATE FOREIGN TABLE sqlserver_dog_breeds (
  breed text,
  top_name text,
  avg_weight_lbs int
)
SERVER pgbridge_srv
OPTIONS (schema_name 'public', table_name 'mssql_dog_breeds');

Query SQL Server from YugabyteDB:


					SELECT breed, top_name
FROM sqlserver_dog_breeds
WHERE avg_weight_lbs >= 60
ORDER BY avg_weight_lbs DESC;

Example:


					yugabyte=# SELECT breed, top_name
yugabyte-# FROM sqlserver_dog_breeds
yugabyte-# WHERE avg_weight_lbs >= 60
yugabyte-# ORDER BY avg_weight_lbs DESC;
       breed        | top_name
--------------------+----------
 German Shepherd    | Max
 Golden Retriever   | Charlie
 Labrador Retriever | Buddy
(3 rows)
What this proves
  • ✔ YugabyteDB (YSQL) can query SQL Server data
    ✔ FDW is excellent for POCs and exploration
    ✔ You can validate schema + queries before migration
What this is not
  • ❌ Not high-throughput ingestion
    ❌ Not a replacement for CDC
    ❌ Not intended for latency-sensitive production paths
Cleanup (optional) (Be careful, one command below will Destroy YugabyteDB!)

					docker rm -f pgbridge mssql >/dev/null
docker network rm fdw-net >/dev/null
yugabyted destroy >/dev/null
echo "✅ Demo environment cleaned up"
Final takeaway 🐕

If you can query it, you can reason about it. FDWs give you a low-friction way to explore legacy systems from YugabyteDB. and decide when and how to migrate properly.

Have Fun!
