Load-balance YSQL connections to YugabyteDB using vanilla C (libpq)

YugabyteDB provides cluster-aware Smart Drivers for Java, Go, and Node.js that automatically route queries to the right node and balance load with full topology awareness.

Starting with PostgreSQL 16, the upstream libpq C client supports load_balance_hosts=random. This option tells libpq to randomize the host list for each new connection, making it easy to distribute sessions across multiple database servers.

Because YugabyteDB’s YSQL API is wire-compatible with PostgreSQL, this feature just works with YugabyteDB.

If you’re writing in C, this is the simplest way to get basic load balancing today… until YugabyteDB’s own cluster-aware Smart Driver for C arrives (currently in the works 🎉).

Why this matters (even if you have a load balancer)

YugabyteDB’s YSQL layer runs on multiple tservers, all capable of serving SQL. If your app or tool can open multiple independent connections, you can shave off a load balancer hop and spread sessions directly at the client:

  • ● Lower latency (one fewer network hop)

  • ● Simpler infra (no L4/L7 in front, when that’s acceptable)

  • ● Easy to test: it’s just a libpq setting

The connection string you need

The magic lives in libpq’s connection parameters:


					# Multiple hosts (and optional matching ports)
host=yb-tserver-1,yb-tserver-2,yb-tserver-3
port=5433,5433,5433

# Recommended goodies
dbname=yugabyte user=yugabyte sslmode=require connect_timeout=5

# Randomize host choice on each new connection (requires libpq 16+)
load_balance_hosts=random



Notes:

  • ● If you provide N hosts and M ports:

    • ○ If M == 1, that single port is used for all hosts.

    • ○ If M == N, each host[i] pairs with port[i].

  • ● Without load_balance_hosts=random, libpq will try hosts in order and only move on if the first fails. With it, the host order is randomized, leading to a more balanced distribution.

Tiny C demo (vanilla libpq)

This program opens --count connections using the same conninfo string and prints where each connection landed via inet_server_addr() and inet_server_port().

c_lbpq_demo.c

					// c_lbpq_demo.c
// Build: gcc c_lbpq_demo.c -o c_lbpq_demo -lpq
// Run:   ./c_lbpq_demo --count 12 --conn "host=h1,h2,h3 port=5433 dbname=yugabyte user=yugabyte sslmode=require load_balance_hosts=random"

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <libpq-fe.h>

static void die(const char *msg) {
  fprintf(stderr, "%s\n", msg);
  exit(EXIT_FAILURE);
}

static void check_ok(PGconn *c) {
  if (PQstatus(c) != CONNECTION_OK) {
    fprintf(stderr, "Connection failed: %s\n", PQerrorMessage(c));
    PQfinish(c);
    exit(EXIT_FAILURE);
  }
}

int main(int argc, char **argv) {
  const char *conninfo = NULL;
  int count = 6;

  // super simple flag parse
  for (int i = 1; i < argc; i++) {
    if (!strcmp(argv[i], "--count") && i+1 < argc) {
      count = atoi(argv[++i]);
    } else if (!strcmp(argv[i], "--conn") && i+1 < argc) {
      conninfo = argv[++i];
    }
  }

  if (!conninfo) {
    fprintf(stderr, "Usage: %s --count N --conn \"<libpq conn string>\"\n", argv[0]);
    fprintf(stderr, "Example conn: host=h1,h2,h3 port=5433 dbname=yugabyte user=yugabyte sslmode=require load_balance_hosts=random\n");
    return EXIT_FAILURE;
  }

  for (int i = 0; i < count; i++) {
    PGconn *c = PQconnectdb(conninfo);
    check_ok(c);

    // Show where we landed
    PGresult *r = PQexec(c, "select inet_server_addr(), inet_server_port(), pg_backend_pid()");
    if (PQresultStatus(r) != PGRES_TUPLES_OK) {
      fprintf(stderr, "Query failed: %s\n", PQerrorMessage(c));
      PQclear(r);
      PQfinish(c);
      return EXIT_FAILURE;
    }

    char *addr = PQgetvalue(r, 0, 0);
    char *port = PQgetvalue(r, 0, 1);
    char *pid  = PQgetvalue(r, 0, 2);

    printf("#%02d -> server=%s:%s backend_pid=%s\n", i+1, addr, port, pid);

    PQclear(r);
    PQfinish(c);
  }

  return EXIT_SUCCESS;
}


Build & run

AlmaLinux 9 / RHEL-like (PG15 client dev headers shown; pick your distro’s package):


					# Enable CRB (needed for dependencies):
sudo dnf config-manager --set-enabled crb

# Install EPEL (for perl-IPC-Run):
sudo dnf install -y epel-release

# Add the PostgreSQL PGDG repo:
sudo dnf install -y https://download.postgresql.org/pub/repos/yum/reporpms/EL-9-x86_64/pgdg-redhat-repo-latest.noarch.rpm

# Disable the built-in PostgreSQL module:
sudo dnf -qy module disable postgresql

# Install PostgreSQL 16 client + dev headers:
sudo dnf install -y perl-IPC-Run postgresql16 postgresql16-devel

# Build the demo program:
gcc c_lbpq_demo.c -o c_lbpq_demo -I/usr/pgsql-16/include -L/usr/pgsql-16/lib -lpq

# Run against your cluster:
./c_lbpq_demo --count 12 --conn \
"host=127.0.0.1,127.0.0.2,127.0.0.3 port=5433 dbname=yugabyte user=yugabyte sslmode=prefer load_balance_hosts=random connect_timeout=5"



Sample output:


					[root@localhost ~]# ./c_lbpq_demo --count 12 --conn "host=127.0.0.1,127.0.0.2,127.0.0.3 port=5433 dbname=yugabyte user=yugabyte sslmode=prefer load_balance_hosts=random connect_timeout=5"
#01 -> server=127.0.0.3:5433 backend_pid=692138
#02 -> server=127.0.0.3:5433 backend_pid=692149
#03 -> server=127.0.0.1:5433 backend_pid=692160
#04 -> server=127.0.0.2:5433 backend_pid=692171
#05 -> server=127.0.0.1:5433 backend_pid=692182
#06 -> server=127.0.0.2:5433 backend_pid=692193
#07 -> server=127.0.0.2:5433 backend_pid=692204
#08 -> server=127.0.0.1:5433 backend_pid=692215
#09 -> server=127.0.0.2:5433 backend_pid=692226
#10 -> server=127.0.0.1:5433 backend_pid=692237
#11 -> server=127.0.0.3:5433 backend_pid=692247
#12 -> server=127.0.0.2:5433 backend_pid=692257


Experiments to try
  • ● Flip load_balance_hosts off

    • Run with it omitted. Connections will prefer the first host unless it’s unavailable.

  • ● Mismatched port list

    • If your port= list is a single value (e.g., 5433), it’s applied to all hosts. If you supply multiple ports (e.g., 5433,5433,6432), libpq pairs host[i] with port[i].

  • ● Fault injection

    • Stop one tserver. With load_balance_hosts=random, new connections will distribute among the remaining healthy hosts. Keep connect_timeout small to avoid delays.

Practical tips
  • ● DNS vs IPs: Prefer DNS names that follow your tserver lifecycle (K8s headless Service, etc.).

  • ● SSL: If sslmode=require, make sure every host supports SSL. Otherwise, use sslmode=prefer for mixed setups.

  • ● Timeouts: Use connect_timeout=5 (or similar) so a down host doesn’t stall your app.

  • ● Pooling: You can still front this with a pool (HikariCP, pgbouncer, YB Connection Manager). Client-side host lists help even pools distribute their initial connections.

Wrapping things up…

With PostgreSQL 16+ client libraries, you get native client-side load balancing via load_balance_hosts=random. Since YugabyteDB’s YSQL is wire-compatible with Postgres, this feature works seamlessly.

It’s a practical workaround for C applications until YugabyteDB’s Smart Driver for C lands, giving you easy, effective distribution of new connections across YSQL servers with just one connection string parameter.
