Fast Row Counts for Partition Key Columns in YSQL


					#!/bin/bash
shopt -s expand_aliases
set -e

# Script:      count_partition_keys.sh
# Description: This script will count the rows from a given table grouped by the partition key columns
#              of the table's primary key.
#
#              The system view yb_local_tablets, if it exists, will be used to determine the partition ranges.
#              (YugabyteDB versions 2024.1.x and beyond). If the view does not exist, then the script will try
#              to access the YB Master UI to determine the partition ranges. If the YB Master UI is not accessable,
#              a set of 16 partion ranges will be used.

# Created:     09/05/2024
# Last update: 09/05/2024

# Edits:
#

# Call Spec:
#   ./count_partition_keys.sh <<Table Name>> <<Database Node IP>> <<Database Name>> <<Database Username>>

# Example Use:
#   ./count_partition_keys.sh public.test 127.0.0.1 yugabyte yugabyte

# Important Notes:
#  1. This script is for YSQL only.
#  2. Table must have a HASH sharded Primary Key defined.
#  3. The table name should be in the format schema.table
#  4. The Database Node IP should preferreably also be running the YB Master process

# For Mac, need to use gnu-sed
# Install with: brew install gnu-sed
# Uncomment the following lines after installing gnu-sed:
# OLD_PATH=$PATH
# PATH="/usr/local/opt/gnu-sed/libexec/gnubin:$PATH"

# Variables
TOPRC=5                     # Limit output to top x rows
TMP_OUT_FILE="/tmp/tc.txt"  # Temp file to write row counts
RCS=64                      # Break up COUNT(*) queries into x pieces

# Verify input parameters

# Check if table name was provided
# Table name must be in the format: schema_name.table_name
if [ -z "$1" ]
then
  echo "Please provide a table name in the format: schema_name.table_name"
  exit 0
else
  YB_SCHEMA_NAME=$(echo $1 | cut -f1 -d.)
  YB_TABLE_NAME=$(echo $1 | cut -f2 -d.)
fi

# Check if IP or hostname was provided
if [ -z "$2" ]
then
  echo "Please provide an IP or hostname for a YB Database Node (preferrably a YB Master node)"
  exit 0
else
  YB_IP=$2
fi

# Check if table database name was provided
if [ -z "$3" ]
then
  echo "Please provide a database name"
  exit 0
else
  YB_DATABASE=$3
fi

# Check if database user name was provided
if [ -z "$4" ]
then
  echo "Please provide a database username"
  exit 0
else
  YB_USER=$4
fi

# Set up the YSQLSH alias below per your environment
YB_PATH='/root/yugabyte-2024.1.1.0/bin/ysqlsh'

alias y="$YB_PATH -h $YB_IP -U $YB_USER -d $YB_DATABASE"
alias y1="$YB_PATH -U $YB_USER -d $YB_DATABASE"

# Check if table exists
tc=`y -Atc "SELECT COUNT(*) FROM pg_tables WHERE schemaname = '$YB_SCHEMA_NAME' AND tablename = '$YB_TABLE_NAME';" | awk '{ print $1'}`

if [ -z "$tc" ]
then
      echo "Database connection failed."
      exit 1
fi

if [ $tc -gt 0 ]
then
  # Get the PK HASH columns for the table.
  HPC=`y -Atc "WITH q AS (SELECT SUBSTR(pg_catalog.pg_get_indexdef(i.indexrelid, 0, true), POSITION('lsm' IN pg_catalog.pg_get_indexdef(i.indexrelid, 0, true))+4) x FROM pg_catalog.pg_index i JOIN pg_catalog.pg_class c ON c.oid = i.indrelid JOIN pg_catalog.pg_class c2 ON c2.oid = i.indexrelid JOIN pg_catalog.pg_class class ON c.oid = class.oid JOIN pg_catalog.pg_namespace n ON n.oid = class.relnamespace JOIN pg_catalog.pg_constraint con ON (conrelid = i.indrelid AND conindid = i.indexrelid AND contype IN ('p')) WHERE n.nspname = '$YB_SCHEMA_NAME' AND class.relname = '$YB_TABLE_NAME' AND (SUBSTR(pg_catalog.pg_get_indexdef(i.indexrelid, 0, true), POSITION('lsm' IN pg_catalog.pg_get_indexdef(i.indexrelid, 0, true))+4) ILIKE '%HASH,%' OR SUBSTR(pg_catalog.pg_get_indexdef(i.indexrelid, 0, true), POSITION('lsm' IN pg_catalog.pg_get_indexdef(i.indexrelid, 0, true))+4) ILIKE '%HASH\)%') ORDER BY i.indisprimary DESC, i.indisunique DESC, c2.relname) SELECT REPLACE(REPLACE(x_1, '(', ''), ')', '') FROM (SELECT SUBSTR(x, 1, CASE WHEN POSITION('HASH,' IN x)-1 <= 1 THEN POSITION('HASH)' IN x)-1 ELSE POSITION('HASH,' IN x)-1 END)  || ')' x_1 FROM q) foo ORDER BY LENGTH(x_1) DESC LIMIT 1;"`

if [ -z "$HPC" ]
then
  echo "The table \"$1\" does not have a HASH sharded primary key defined."
  exit 1
fi
  START=0
  INC=$((65536/$RCS))
  END=$((65536-$INC))

  # Remove temp file
  rm -fr $TMP_OUT_FILE

  # Get the list of T-Servers
  HOSTS=`y -Atc "SELECT string_agg(host, '|') host FROM yb_servers();"`
  IFS="|" read -a HOSTS_A <<< $HOSTS

  echo $HOSTS

  for COUNTER in $(eval echo "{$START..$END..$INC}")
  do
    RAND=$[$RANDOM % ${#HOSTS_A[@]}]
    y1 -h ${HOSTS_A[$RAND]} -c "SET default_transaction_read_only = TRUE;" -c "SET yb_read_from_followers = TRUE;" -Atc "SELECT $HPC, COUNT(1) FROM $YB_SCHEMA_NAME.$YB_TABLE_NAME WHERE yb_hash_code($HPC) BETWEEN $COUNTER AND $(($COUNTER+$INC-1)) GROUP BY $HPC;" >> $TMP_OUT_FILE &
    echo "SELECT $HPC, COUNT(1) FROM $YB_SCHEMA_NAME.$YB_TABLE_NAME WHERE yb_hash_code($HPC) BETWEEN $COUNTER AND $(($COUNTER+$INC-1)) GROUP BY $HPC;"
  done

  wait

  # Display top TOPRC row count
  sort -r -n -t '|' -k2 $TMP_OUT_FILE | head -$TOPRC | column -t -s '|' --table-columns PARTITION,COUNT

  # Clean up temp file
  rm -fr $TMP_OUT_FILE

else
  echo "Table \"$1\" does not exist."

fi

exit 0
